#include <field-interface.h>
|
| virtual | ~FieldInterface ()=default |
| |
| virtual std::string_view | name () const =0 |
| | Get the name of the field without level delimiters.
|
| |
| virtual const std::string & | description () const =0 |
| | Get the description of the field.
|
| |
| virtual unsigned | number_of_bits () const =0 |
| |
| virtual void | init (std::string_view desc, const bits_type &bits, int8_t offset)=0 |
| | Initialize the field with a description, size in bits and an offset.
|
| |
| virtual RegisterInterface * | parent () const =0 |
| |
| virtual | ~ValueAccessorInterface ()=default |
| |
| virtual uint64_t | get () const =0 |
| |
| virtual uint64_t | read (uint64_t enabled_bits)=0 |
| |
| virtual | ~ValueMutatorInterface ()=default |
| |
| virtual void | set (uint64_t value)=0 |
| |
| virtual void | write (uint64_t value, uint64_t enabled_bits)=0 |
| |
◆ ~FieldInterface()
| virtual simics::FieldInterface::~FieldInterface |
( |
| ) |
|
|
virtualdefault |
◆ description()
| virtual const std::string & simics::FieldInterface::description |
( |
| ) |
const |
|
pure virtual |
Get the description of the field.
- Returns
- A reference to the string containing the field description.
Implemented in simics::Field.
◆ init()
| virtual void simics::FieldInterface::init |
( |
std::string_view |
desc, |
|
|
const bits_type & |
bits, |
|
|
int8_t |
offset |
|
) |
| |
|
pure virtual |
Initialize the field with a description, size in bits and an offset.
Typically called after the field is instantiated.
- Parameters
-
| offset | is the offset of the first bit in the containing register |
Implemented in simics::ConstantField, and simics::Field.
◆ name()
| virtual std::string_view simics::FieldInterface::name |
( |
| ) |
const |
|
pure virtual |
Get the name of the field without level delimiters.
- Returns
- A string view representing the field name only.
Implemented in simics::Field.
◆ number_of_bits()
| virtual unsigned simics::FieldInterface::number_of_bits |
( |
| ) |
const |
|
pure virtual |
- Returns
- the number of bits for this field
Implemented in simics::Field.
◆ parent()
- Returns
- the parent register interface
Implemented in simics::Field.
The documentation for this class was generated from the following file:
- /disk2/mp/builds/nightly-base.745.16951401086.1/src/devices/c++-api/simics/field-interface.h
Public Member Functions inherited from simics::ValueAccessorInterface
