SystemC Library API Reference Manual
Reference documentation for the Simics SystemC Library.
|
|
|
SystemC Library API Reference Manual
Reference documentation for the Simics SystemC Library.
|
|
#include <proxy_initiator_gasket.h>
Public Member Functions | |
| ProxyInitiatorGasket (simics::ConfObjectRef o) | |
| virtual void | init (sc_core::sc_object *obj, SimulationInterface *simulation) |
 Public Member Functions inherited from simics::systemc::awareness::Proxy | |
| Proxy (simics::ConfObjectRef o) | |
| virtual void | init (sc_core::sc_object *obj, iface::SimulationInterface *simulation) |
| virtual void | allProxiesInitialized () |
| virtual void | set_attributes (Attributes *attributes) |
| std::vector< std::string > | sc_print () const |
| std::vector< std::string > | sc_dump () const |
| attr_value_t | sc_kind () const |
| const char * | sc_name () const |
| void | breakSimulation () |
| ConfObjectRef | simics_obj () |
| sc_core::sc_object * | systemc_obj () |
| void | buildEventObjects () |
| virtual iface::SimulationInterface * | simulation () |
| virtual void | addFeature (ProxyFeatureInterface *feature) |
| virtual ProxyFeatureInterface * | feature (ClassType type) |
| virtual void | simulationStarted () |
| virtual void | simulationEnded () |
| virtual void | resizeExtensions (tlm::tlm_generic_payload *payload) const |
| template<class T > | |
| T * | feature () |
| virtual | ~Proxy () |
| Public Member Functions inherited from simics::systemc::awareness::ProxyInterface | |
| virtual void | init (sc_core::sc_object *obj, iface::SimulationInterface *simulation)=0 |
| virtual void | allProxiesInitialized ()=0 |
| virtual void | breakSimulation ()=0 |
| virtual ConfObjectRef | simics_obj ()=0 |
| virtual sc_core::sc_object * | systemc_obj ()=0 |
| virtual void | buildEventObjects ()=0 |
| virtual iface::SimulationInterface * | simulation ()=0 |
| virtual void | addFeature (ProxyFeatureInterface *feature)=0 |
| virtual ProxyFeatureInterface * | feature (ClassType type)=0 |
| virtual void | simulationStarted ()=0 |
| virtual void | simulationEnded ()=0 |
| virtual | ~ProxyInterface () |
| Public Member Functions inherited from simics::systemc::iface::ScObjectInterface | |
| virtual std::vector< std::string > | sc_print () const =0 |
| virtual std::vector< std::string > | sc_dump () const =0 |
| virtual attr_value_t | sc_kind () const =0 |
| virtual const char * | sc_name () const =0 |
| virtual | ~ScObjectInterface () |
| Public Member Functions inherited from simics::systemc::SimulationInterfaceProxy | |
| SimulationInterfaceProxy () | |
| void | setSimulation (iface::SimulationInterface *simulation) |
| virtual int | runDeltaPhase (int count) |
| virtual bool | runSimulation (sc_core::sc_time t) |
| virtual void | stopSimulation () |
| virtual sc_core::sc_simcontext * | context () const |
| virtual ConfObjectRef | simics_object () const |
| Public Member Functions inherited from simics::systemc::iface::SimulationInterface | |
| virtual | ~SimulationInterface () |
| virtual int | runDeltaPhase (int count)=0 |
| virtual bool | runSimulation (sc_core::sc_time t)=0 |
| virtual void | stopSimulation ()=0 |
| virtual sc_core::sc_simcontext * | context () const =0 |
| virtual ConfObjectRef | simics_object () const =0 |
| Public Member Functions inherited from simics::systemc::awareness::ScInitiatorGasket | |
| ScInitiatorGasket (simics::ConfObjectRef obj) | |
| void | init (sc_core::sc_object *obj) |
| virtual void | set_dmi (bool enable) |
| virtual bool | is_dmi_enabled () |
| virtual char * | print_dmi_table () |
| Public Member Functions inherited from simics::systemc::iface::ScInitiatorGasketInterface | |
| virtual void | set_dmi (bool enable)=0 |
| virtual bool | is_dmi_enabled ()=0 |
| virtual char * | print_dmi_table ()=0 |
| virtual | ~ScInitiatorGasketInterface () |
Additional Inherited Members | |
| Static Public Member Functions inherited from simics::systemc::awareness::Proxy | |
| static attr_value_t | getAttribute (lang_void *ptr, conf_object_t *obj, attr_value_t *idx) |
| static set_error_t | setAttribute (lang_void *ptr, conf_object_t *obj, attr_value_t *val, attr_value_t *idx) |
| static ProxyInterface * | findProxy (sc_core::sc_object *obj) |
| static ProxyInterface * | findProxy (sc_core::sc_interface *iface) |
| static ScEventObject * | findScEventObject (sc_core::sc_event *event) |
| Protected Attributes inherited from simics::systemc::awareness::Proxy | |
| sc_core::sc_object * | object_ |
| sc_core::sc_interface * | iface_ |
| Protected Attributes inherited from simics::systemc::awareness::ScInitiatorGasket | |
| simics2tlm::GasketInterface * | gasket_ |
| simics::ConfObjectRef | simics_obj_ |
|
inlineexplicit |
|
inlinevirtual |
