Normally a bank allocates memory from the device object using the name of the bank as the key. More...
#include <bank-templates.h>
Public Member Functions | |
| SharedMemoryBank (MappableConfObject *dev_obj, const std::string &name, std::string_view name_of_bank_memory) | |
 Public Member Functions inherited from simics::Bank | |
| Bank (MappableConfObject *dev_obj, const std::string &name) | |
| Bank (MappableConfObject *dev_obj, const std::string &name, ByteOrder byte_order) | |
| Bank (const Bank &)=delete | |
| Bank & | operator= (const Bank &)=delete |
| Bank (Bank &&rhs) | |
| Bank & | operator= (Bank &&rhs) |
| virtual | ~Bank ()=default |
| std::string_view | name () const override |
| Get the name of the bank without level delimiters. | |
| MappableConfObject * | dev_obj () const override |
| Get the device object. | |
| const std::string & | description () const override |
| Get the description of the bank. | |
| void | set_description (std::string_view desc) override |
| Set the description for the bank. | |
| void | add_register (const register_t ®) override |
| Parse a register name and add register to the bank. | |
| void | add_register (std::string_view name, std::string_view desc, Offset offset, ByteSize number_of_bytes, InitValue init_value, const std::vector< field_t > &fields) override |
| Add a register to the bank. | |
| unsigned | number_of_registers () const override |
| Get the number of registers in the bank. | |
| std::pair< size_t, RegisterInterface * > | register_at_index (unsigned index) const override |
| Get the register at a specific index. | |
| const std::map< size_t, RegisterInterface * > & | mapped_registers () const override |
| Get all mapped registers on the bank ordered by offset. | |
| void | set_callbacks (BankIssueCallbacksInterface *callbacks) override |
| Set the callbacks for bank issues. | |
| ByteOrder | get_byte_order () const override |
| Get the byte order of the bank. | |
| void | set_miss_pattern (uint8_t miss_pattern) override |
| Set the miss pattern for the bank. | |
| exception_type_t | transaction_access (transaction_t *t, uint64_t offset) override |
| Entry point for a memory access from the transaction interface. | |
| Public Member Functions inherited from simics::BankInterface | |
| virtual | ~BankInterface ()=default |
| virtual std::string_view | name () const =0 |
| Get the name of the bank without level delimiters. | |
| virtual MappableConfObject * | dev_obj () const =0 |
| Get the device object. | |
| virtual const std::string & | description () const =0 |
| Get the description of the bank. | |
| virtual void | set_description (std::string_view desc)=0 |
| Set the description for the bank. | |
| virtual void | add_register (const register_t ®)=0 |
| Parse a register name and add register to the bank. | |
| virtual void | add_register (std::string_view name, std::string_view desc, Offset offset, ByteSize number_of_bytes, InitValue init_value, const std::vector< field_t > &fields)=0 |
| Add a register to the bank. | |
| virtual unsigned | number_of_registers () const =0 |
| Get the number of registers in the bank. | |
| virtual std::pair< size_t, RegisterInterface * > | register_at_index (unsigned index) const =0 |
| Get the register at a specific index. | |
| virtual const std::map< size_t, RegisterInterface * > & | mapped_registers () const =0 |
| Get all mapped registers on the bank ordered by offset. | |
| virtual void | set_callbacks (BankIssueCallbacksInterface *callbacks)=0 |
| Set the callbacks for bank issues. | |
| virtual ByteOrder | get_byte_order () const =0 |
| Get the byte order of the bank. | |
| virtual void | set_miss_pattern (uint8_t miss_pattern)=0 |
| Set the miss pattern for the bank. | |
| virtual exception_type_t | transaction_access (transaction_t *t, uint64_t offset)=0 |
| Entry point for a memory access from the transaction interface. | |
| Public Member Functions inherited from simics::HierarchicalObject | |
| HierarchicalObject (MappableConfObject *dev_obj, const std::string &name) | |
| Constructor for HierarchicalObject. | |
| virtual | ~HierarchicalObject () |
| HierarchicalObject (const HierarchicalObject &)=delete | |
| HierarchicalObject & | operator= (const HierarchicalObject &)=delete |
| HierarchicalObject (HierarchicalObject &&rhs) noexcept | |
| HierarchicalObject & | operator= (HierarchicalObject &&rhs) noexcept |
| template<typename T > | |
| T * | dev_ptr () |
| const std::string & | hierarchical_name () const override |
| std::string_view | name () const override |
| const std::string & | description () const override |
| void | set_description (std::string_view desc) override |
| Level | hierarchy_level () const override |
| std::string_view | bank_name () const override |
| MappableConfObject * | dev_obj () const override |
| ConfObjectRef | bank_obj_ref () const override |
| std::string_view | parent_name () const override |
| FieldInterface * | lookup_field (const std::string &name) const override |
| RegisterInterface * | lookup_register (const std::string &name) const override |
| BankInterface * | lookup_bank (const std::string &name) const override |
| virtual const std::string & | hierarchical_name () const =0 |
| virtual std::string_view | name () const =0 |
| virtual const std::string & | description () const =0 |
| virtual void | set_description (std::string_view desc)=0 |
| virtual Level | hierarchy_level () const =0 |
| virtual std::string_view | bank_name () const =0 |
| virtual MappableConfObject * | dev_obj () const =0 |
| virtual ConfObjectRef | bank_obj_ref () const =0 |
| virtual std::string_view | parent_name () const =0 |
| virtual FieldInterface * | lookup_field (const std::string &name) const =0 |
| virtual RegisterInterface * | lookup_register (const std::string &name) const =0 |
| virtual BankInterface * | lookup_bank (const std::string &name) const =0 |
Additional Inherited Members | |
| Static Public Member Functions inherited from simics::HierarchicalObject | |
| static bool | is_valid_hierarchical_name (std::string_view name) |
| static std::string_view::size_type | level_of_hierarchical_name (std::string_view name) |
| Static Public Attributes inherited from simics::HierarchicalObject | |
| static const uint64_t | Register_Read {1} |
| Log group ID for Register_Read and Register_Write is fixed. | |
| static const uint64_t | Register_Write {2} |
| static const uint64_t | Register_Read_Exception {3} |
| static const uint64_t | Register_Write_Exception {4} |
| Protected Member Functions inherited from simics::Bank | |
| virtual std::vector< uint8_t > | read (uint64_t offset, size_t size, Inquiry inquiry=Inquiry::NonInquiry) const |
| virtual void | write (uint64_t offset, const std::vector< uint8_t > &value, size_t size, Inquiry inquiry=Inquiry::NonInquiry) const |
| virtual void | unmapped_read (size_t offset, size_t size) const |
| virtual void | unmapped_write (size_t offset, size_t size) const |
| void | allocate_bank_memory (std::string_view name) |
| Allocate memory for this bank by name. | |
Normally a bank allocates memory from the device object using the name of the bank as the key.
SharedMemoryBank supports using any string when allocating the bank memory. It can be used when multiple banks are sharing the same bank memory.
|
inline |
| name_of_bank_memory | the name of the bank memory |
