Generating Model Card for Multimodal Classification with PyTorch and Roberta Models
This notebook provides an example of generating a model card for multimodal vision and text classification using PyTorch and Roberta models. The model is trained to classify meme images and text to identify hateful memes. Finally, we use the Intel Model Card Generator for analyzing the performance of our model.
1. Download and Import Dependencies
[ ]:
!pip install evaluate datasets transformers[torch] scikit-learn torchvision Pillow
[48]:
import torch.nn as nn
import torch.optim as optim
import json
from torch.utils.data import Dataset, DataLoader
from PIL import Image
import torch
from sklearn.model_selection import train_test_split
from torchvision import transforms
from transformers import RobertaTokenizer, RobertaModel
import torch.nn.functional as F
import numpy as np
from sklearn.metrics import precision_score, recall_score, f1_score, accuracy_score
import pandas as pd
from intel_ai_safety.model_card_gen.model_card_gen import ModelCardGen
2. Download Dataset from Hugging Face Datasets
[ ]:
from datasets import load_dataset
ds = load_dataset("neuralcatcher/hateful_memes")
Train Test Split
[7]:
dataset = ds['train'].train_test_split(test_size=0.2)
dataset
[7]:
DatasetDict({
train: Dataset({
features: ['id', 'img', 'label', 'text'],
num_rows: 6800
})
test: Dataset({
features: ['id', 'img', 'label', 'text'],
num_rows: 1700
})
})
[8]:
train_data = dataset["train"]
test_data = dataset["test"]
Viewing an example Image from the Dataset
[10]:
item = train_data[0]
Image.open(item['img']).convert('RGB')
[10]:
3. Transform the Image and Text Features of the Dataset
[11]:
class CustomDataset(Dataset):
def __init__(self, data, transform=None, tokenizer=None, text_model=None):
self.data = data
self.tokenizer = tokenizer
self.text_classification_model = text_model
def __len__(self):
return len(self.data)
def __getitem__(self, idx):
item = self.data[idx]
transform = transforms.Compose([
transforms.Resize((224, 224)), # Resize images
transforms.ToTensor(), # Convert to tensor
transforms.Normalize(mean=[0.5, 0.5, 0.5], std=[0.5, 0.5, 0.5]) # Normalize
])
# Process Image
img = Image.open(item['img']).convert('RGB')
img = transform(img)
# Process Text
text_features = None
inputs = self.tokenizer(item['text'], return_tensors="pt", padding=True, truncation=True, max_length=512)
with torch.no_grad():
outputs = self.text_classification_model(**inputs)
text_features = outputs.last_hidden_state.mean(dim=1).squeeze(0)
return {
"image": img,
"text_features": text_features,
"label": torch.tensor(item['label'], dtype=torch.long)
}
Load the Text Model
[ ]:
from transformers import RobertaTokenizer, RobertaModel
tokenizer = RobertaTokenizer.from_pretrained('roberta-base')
text_model = RobertaModel.from_pretrained('roberta-base')
[13]:
train_dataset = CustomDataset(train_data, tokenizer=tokenizer, text_model=text_model)
test_dataset = CustomDataset(test_data, tokenizer=tokenizer, text_model=text_model)
Preparing Data Loaders for Training and Testing
[14]:
train_loader = DataLoader(train_dataset, batch_size=32, shuffle=True)
test_loader = DataLoader(test_dataset, batch_size=32, shuffle=False)
4. Build Model
[17]:
class HatefulMemeClassifier(nn.Module):
def __init__(self, text_dim, img_dim, num_classes):
super(HatefulMemeClassifier, self).__init__()
self.text_fc1 = nn.Linear(text_dim, 512)
self.text_bn1 = nn.BatchNorm1d(512)
self.text_fc2 = nn.Linear(512, 256)
self.text_bn2 = nn.BatchNorm1d(256)
self.img_fc1 = nn.Linear(img_dim, 512)
self.img_bn1 = nn.BatchNorm1d(512)
self.img_fc2 = nn.Linear(512, 256)
self.img_bn2 = nn.BatchNorm1d(256)
self.dropout = nn.Dropout(0.5)
self.fc = nn.Linear(256 * 2, num_classes)
def forward(self, text_features, img_features):
text_out = F.relu(self.text_bn1(self.text_fc1(text_features)))
text_out = self.dropout(F.relu(self.text_bn2(self.text_fc2(text_out))))
img_out = F.relu(self.img_bn1(self.img_fc1(img_features)))
img_out = self.dropout(F.relu(self.img_bn2(self.img_fc2(img_out))))
combined = torch.cat((text_out, img_out), dim=1)
return self.fc(combined)
[18]:
device = torch.device("cuda" if torch.cuda.is_available() else "cpu")
model = HatefulMemeClassifier(text_dim=768, img_dim=3 * 224 * 224, num_classes=2).to(device)
optimizer = optim.Adam(model.parameters(), lr=0.001)
criterion = nn.CrossEntropyLoss()
5. Train Model
[ ]:
epochs=5
i = 0
for epoch in range(epochs):
model.train()
for batch in train_loader:
i+=1
images = batch['image'].to(device).view(batch['image'].size(0), -1)
text_features = batch['text_features'].to(device)
labels = batch['label'].to(device)
optimizer.zero_grad()
outputs = model(text_features, images)
loss = criterion(outputs, labels)
loss.backward()
optimizer.step()
print(i)
print(f"Epoch {epoch + 1}/{epochs}, Loss: {loss.item():.4f}")
6. Save Model
Save the offline version of trained multimodal classification model.
[ ]:
torch.save(model.state_dict(), 'hatefule_meme_classifier.pth')
7. Evaluate Model
Evaluating Model Performance on Test Dataset
[31]:
model.eval()
correct, total = 0, 0
y_pred_prob = []
with torch.no_grad():
for batch in test_loader:
images = batch['image'].to(device).view(batch['image'].size(0), -1)
text_features = batch['text_features'].to(device)
labels = batch['label'].to(device)
outputs = model(text_features, images)
probs = torch.softmax(outputs, dim=1)[:, 1]
_, predicted = torch.max(outputs, 1)
total += labels.size(0)
correct += (predicted == labels).sum().item()
y_pred_prob.extend(probs.cpu().numpy())
print(f"Test Accuracy: {100 * correct / total:.2f}%")
Test Accuracy: 68.71%
8. Transform Output for Model Card
We will create metrics_by_threshold dataframe containing performance metrics at threshold.
[ ]:
thetas = np.linspace(0, 1, 1001)
metrics_dict ={
'threshold': thetas,
'precision': [precision_score(test_data['label'], y_pred_prob > theta) for theta in thetas],
'recall': [recall_score(test_data['label'], y_pred_prob > theta) for theta in thetas],
'f1': [f1_score(test_data['label'], y_pred_prob > theta) for theta in thetas],
'accuracy' : [accuracy_score(test_data['label'], y_pred_prob > theta) for theta in thetas]
}
[41]:
metrics_by_threshold = pd.DataFrame.from_dict(metrics_dict)
[42]:
metrics_by_threshold.to_csv('metrics_by_threshold_multimodal.csv', index=False)
9. Generate Model Card
Simply load the metrics_by_threshold dataframe into the ModelCardGen.generate class method to build a model card.
[43]:
metrics_by_threshold = pd.read_csv("metrics_by_threshold_multimodal.csv")
[52]:
mc = {
"schema_version": "0.0.1",
"model_details": {
"name": "Hateful Meme Classification",
"version": {
"name": "0.1",
"date": "2024"
},
"graphics": {},
"citations": [
{
"citation": '''@misc{liu2019robertarobustlyoptimizedbert,
title={RoBERTa: A Robustly Optimized BERT Pretraining Approach},
author={Yinhan Liu and Myle Ott and Naman Goyal and Jingfei Du and Mandar Joshi and Danqi Chen and Omer Levy and Mike Lewis and Luke Zettlemoyer and Veselin Stoyanov},
year={2019},
eprint={1907.11692},
archivePrefix={arXiv},
primaryClass={cs.CL},
url={https://arxiv.org/abs/1907.11692},
}'''
},
{
"citation": '''@misc{kiela2021hatefulmemeschallengedetecting,
title={The Hateful Memes Challenge: Detecting Hate Speech in Multimodal Memes},
author={Douwe Kiela and Hamed Firooz and Aravind Mohan and Vedanuj Goswami and Amanpreet Singh and Pratik Ringshia and Davide Testuggine},
year={2021},
eprint={2005.04790},
archivePrefix={arXiv},
primaryClass={cs.AI},
url={https://arxiv.org/abs/2005.04790},
}
'''
}
],
"overview": 'This example of a multimodal PyTorch model uses text features generated by the RoBERTa model and meme images to classify a meme image and text as either hateful or normal. The PyTorch model is trained on the Hateful Memes Challenge dataset created by Facebook AI for detecting hate speech in multimodal memes.',
}
}
[53]:
mcg = ModelCardGen.generate(metrics_by_threshold=metrics_by_threshold, model_card=mc)
mcg
[53]:
Model Details
Overview
This example Multimodal Pytorch model uses text features generated using Roberta Model and meme images for classifying an meme image and text as either Hateful or Normal.Model Performance
Overall Accuracy/Precision/Recall/F1
Version
name: 0.1
date: 2024
Citations
- @misc{liu2019robertarobustlyoptimizedbert, title={RoBERTa: A Robustly Optimized BERT Pretraining Approach}, author={Yinhan Liu and Myle Ott and Naman Goyal and Jingfei Du and Mandar Joshi and Danqi Chen and Omer Levy and Mike Lewis and Luke Zettlemoyer and Veselin Stoyanov}, year={2019}, eprint={1907.11692}, archivePrefix={arXiv}, primaryClass={cs.CL}, url={https://arxiv.org/abs/1907.11692}, }
- @misc{kiela2021hatefulmemeschallengedetecting, title={The Hateful Memes Challenge: Detecting Hate Speech in Multimodal Memes}, author={Douwe Kiela and Hamed Firooz and Aravind Mohan and Vedanuj Goswami and Amanpreet Singh and Pratik Ringshia and Davide Testuggine}, year={2021}, eprint={2005.04790}, archivePrefix={arXiv}, primaryClass={cs.AI}, url={https://arxiv.org/abs/2005.04790}, }
